1 4

Stylus VNL I

Stylus VNL \

Output voltage at 1000Hz, 5cm/sec. - 6 mV.
Channel separation at 1kHz - 20 dB.
Frequency response 20 Hz - 20 kHz -2/+4 dB.
Tracking ability at 315 Hz at recommended tracking force - 100 μm.
Compliance, dynamic lateral - 16 μm/mN.
Tracking force range - 3 - 5 g.
Tracking force recommended - 4 g.
€39,00
Find nearest dealer

Stylus VNL I

Output voltage at 1000 Hz, 5cm/sec. - 6 mV. Channel separation at 1 kHz - 20 dB. Frequency response 20 Hz - 20 kHz  -2/+4 dB. Tracking ability at 315 Hz at recommended tracking force - 100 μm. Compliance, dynamic lateral - 16 μm/mN. Tracking force range - 3 - 5 g. Tracking force recommended - 4 g.

For information about set-up and alignment, stylus care and lifetime, break-in time, and troubleshooting, check out our DJ FAQ.

Download the VNL userguide

Download Concorde MkII Universal & VNL styli datasheet

Specifications
  • Channel seperation at 1 kHz
    20 dB
  • Frequency response 20 Hz - 20 kHz
    2/+4 dB
  • Tracking ability at 315Hz at recommended tracking force
    100 μm
  • Compliance, dynamic, lateral
    16 μm/mN
  • Tracking force range
    3 - 5 g
  • Tracking force, recommended
    4 g
    • Download userguide
