OM Scratch White mounted on SH-4 Blue headshell

OM Scratch White Premounted

The OM Scratch White on the SH-4 Black headshell is a practical and convenient solution for our customers who wish direct and easy mounting and replacement on their S-shaped tonearm.
€139,00
Find nearest dealer
OverviewFeaturesReviewsSpecifications

OM Scratch White mounted on SH-4 Blue headshell

Features:

• Universal mount fitting a wide range of S-shaped tonearms

• Correct Baerwald alignment with the major part of tonearms with universal mount

• Increased tracking ability

• Reinforced rubber suspension

High output and maximum scratch performance guaranteed!

Specifications
  • Channel balance at 1 kHz
    1,5 dB
  • Output voltage at 1 kHz, 5cm/sec
    7 mV
  • Channel seperation at 1 kHz
    25 dB
  • Channel seperation at 15 kHz
    15 dB
  • Frequency response 20 Hz - 20 kHz
    3dB/-2dB
  • Tracking ability at 315Hz at recommended tracking force
    80 μm
  • Compliance, dynamic, lateral
    6 μm/m N
  • Stylus type
    Spherical
  • Stylus tip radius
    R 18 μm
  • Tracking force range
    3,0-5,0 g (30-50 mN)
  • Tracking force, recommended
    4,0 g (40 mN)
  • Tracking angle
    20°
  • Internal impedance, DC resistance
    750 Ohm
  • Cartridge weight
    5 g (incl headshell = 18.5 g)
  • Recommended load resistance
    47 kOhm
  • Internal inductance
    450 mH
  • Recommended load capacitance
    200-600 pF
  • Replacement stylus
    Stylus MFS
