Ortofon X1-MC and X1-MCP are very high output MC cartridges

Both the X1-MC and the X1-MCP are very high output moving coil (MC) cartridges with an elliptical stylus profile. The X1-MCP was designed for use with P-Mount (T4P) type tonearms. Perfect for inbuilt phono preamps or standard moving magnet (MM) preamps, the X1-MC and the X1-MCP profiled a taste of the linearity and precision of moving coils without the need for additional high gain preamps or transformers.

X1-MCP Technical data

Output voltage at 1000 Hz, 5cm/sec.  -   2 mV
Channel balance at 1 kHz  -   < 2 dB
Channel separation at 1 kHz   -  > 22 dB
Channel separation at 15 kHz   -  > 15 dB
Frequency range at - 3dB -    20-25.000 Hz
Frequency response  -   20-20.000 Hz + 4 / - 1,5 dB
Tracking ability at 315Hz at recommended tracking force  -   > 60 µm
Compliance, dynamic, lateral  -   13 µm/mN
Stylus type  -   Elliptical
Stylus tip radius  -   r/R 8/18 µm

Tracking force range  -   1,25-1,50 g (12,5-15,0 mN)
Tracking force, recommended  -   1,25 g (12,5 mN)
Tracking angle   -  20°
Internal impedance, DC resistance  -   80 Ohm
Recommended load impedance  -   47 kOhm / < 500 pF
Cartridge body material  -   Noryl
Cartridge colour  -   Blue
Cartridge weight  -   6 g
