Technical data
Technical data
Conductor material: Pure Copper Ultra High Drawability (PCUHD), HiFC (High performance pure copper), OFC (Oxygen Free Copper)
Conductor size: 2 .5 x 4
Cable diameter: 14.0 mm
Conductor resistance: 8 mΩ/m Insulation resistance: AC 500 V/min.
Shield: Aluminum Tape
Insulation material: High elastic elastomer, Polyethylene
Cable length: 40 m/roll
Conductor size: 2 .5 x 4
Cable diameter: 14.0 mm
Conductor resistance: 8 mΩ/m Insulation resistance: AC 500 V/min.
Shield: Aluminum Tape
Insulation material: High elastic elastomer, Polyethylene
Cable length: 40 m/roll
